電纜橋架的接地電阻檢測是保障電氣的重要環節，其目的是驗證接地系統是否能有效將故障電流導入大地，防止觸電或設備損壞事故。檢測需遵循規范流程，確保數據準確可靠，以下是具體方法說明。

　　The detection of grounding resistance in cable trays is an important part of ensuring electrical safety. Its purpose is to verify whether the grounding system can effectively guide fault currents into the ground, preventing electric shock or equipment damage accidents. Testing must follow standardized procedures to ensure accurate and reliable data. The following are specific method instructions.

　　檢測前的準備工作需細致到位。需明確檢測標準，根據相關規范，電纜橋架接地電阻值通常要求不大于 4 歐姆，特殊環境下需符合更嚴格的要求（如爆炸危險場所可能要求不大于 1 歐姆）。準備合適的檢測儀器，常用的有接地電阻測試儀（如鉗形接地電阻儀、手搖式接地電阻表），使用前需檢查儀器是否在校驗有效期內，量程是否匹配檢測需求，接線端子是否完好。清理檢測點周圍環境，移除地面雜物、積雪、油污等，確保接地體與測試儀的連接部位清潔，避免接觸不良影響讀數。同時，確認電纜橋架的接地裝置結構，明確接地體、接地線的走向，找出各連接點（如橋架之間的跨接線、與接地干線的連接點），為檢測點的選擇提供依據。

　　The preparation work before testing needs to be meticulous and thorough. Firstly, it is necessary to clarify the testing standards. According to relevant regulations, the grounding resistance value of cable trays is usually required to be no more than 4 ohms. In special environments, stricter requirements must be met (such as explosive hazardous areas where no more than 1 ohm may be required). Prepare suitable testing instruments, commonly used ones include grounding resistance testers (such as clamp type grounding resistance meters, hand cranked grounding resistance meters). Before use, check whether the instrument is within the valid calibration period, whether the range matches the testing requirements, and whether the wiring terminals are intact. Clean up the surrounding environment of the testing point, remove ground debris, snow, oil stains, etc., ensure that the connection between the grounding body and the tester is clean, and avoid adverse contact that may affect readings. At the same time, confirm the grounding device structure of the cable tray, clarify the direction of the grounding body and grounding wire, and identify each connection point (such as the jumper wire between the trays and the connection point with the grounding main line), providing a basis for the selection of detection points.

　　檢測點的選擇直接影響結果的代表性。應優先選擇橋架系統的關鍵節點，如進出建筑物處的接地連接點、橋架分段連接處的跨接線、與接地極直接連接的部位等。對于大型橋架系統，需在不同區域選取多個檢測點，避免因局部接地不良導致整體判斷失誤。檢測點需確保與接地體可靠連接，若連接部位有漆層、氧化層，需用砂紙輕輕打磨露出金屬光澤，保證測試探頭與接地體的良好接觸。

　　The selection of detection points directly affects the representativeness of the results. Priority should be given to selecting key nodes of the bridge system, such as grounding connection points at the entrance and exit of the building, jumper wires at the segmented connection of the bridge, and parts directly connected to the grounding electrode. For large-scale bridge systems, multiple detection points need to be selected in different areas to avoid overall judgment errors caused by poor local grounding. The detection point must be reliably connected to the grounding body. If there is a paint layer or oxide layer on the connection part, it needs to be lightly sanded with sandpaper to expose the metallic luster, ensuring good contact between the test probe and the grounding body.

　　具體檢測操作需按儀器類型規范進行。使用手搖式接地電阻表時，需按 “E”（接地極）、“P”（電位探針）、“C”（電流探針）的順序接線，將探針按直線排列插入地面，間距約 5 米，E 端連接橋架接地體，P、C 端分別連接對應探針。勻速搖動儀表手柄（通常每分鐘 120 轉），待指針穩定后讀取數值，重復測量 2-3 次取平均值。使用鉗形接地電阻儀時，操作更為簡便，只需打開鉗口夾住橋架的接地線或接地體，按下測試鍵，儀器即可顯示電阻值，適合對跨接線、接地干線等部位的快速檢測。檢測過程中需避免人員觸碰探針或接線，防止干擾讀數或發生觸電風險。

　　The specific testing operation needs to be carried out according to the instrument type specifications. When using a hand cranked grounding resistance meter, it is necessary to connect the wires in the order of "E" (grounding electrode), "P" (potential probe), and "C" (current probe). Insert the probes into the ground in a straight line with a spacing of about 5 meters. Connect the E end to the bridge grounding body, and connect the P and C ends to the corresponding probes. Shake the instrument handle at a constant speed (usually 120 revolutions per minute), wait for the pointer to stabilize, read the value, and repeat the measurement 2-3 times to take the average. When using a clamp type grounding resistance meter, the operation is more convenient. Simply open the clamp to clamp the grounding wire or grounding body of the bridge, press the test button, and the instrument will display the resistance value. It is suitable for rapid detection of jumper wires, grounding main lines, and other parts. During the testing process, it is necessary to avoid personnel touching the probe or wiring to prevent interference with readings or the risk of electric shock.

　　檢測后的數據處理與判斷是關鍵。若測得電阻值小于或等于規定標準，說明接地系統合格；若大于標準值，需查找原因，可能是接地體腐蝕、連接松動、接地體埋深不足等。此時可分段檢測，逐步排查故障點，例如斷開橋架之間的跨接線，分別檢測各段接地電阻，確定不良區段后進行修復（如更換腐蝕的接地體、緊固松動的連接螺栓、增加接地極數量等）。修復后需重新檢測，直電阻值符合要求。

　　The processing and judgment of data after detection are crucial. If the measured resistance value is less than or equal to the specified standard, it indicates that the grounding system is qualified; If it is greater than the standard value, the cause needs to be investigated, which may be corrosion of the grounding body, loose connection, insufficient burial depth of the grounding body, etc. At this point, segmented detection can be carried out to gradually identify the fault points, such as disconnecting the jumper wires between the bridge frames, testing the grounding resistance of each section separately, and repairing the defective sections (such as replacing corroded grounding bodies, tightening loose connecting bolts, increasing the number of grounding electrodes, etc.). After repair, it is necessary to retest until the resistance value meets the requirements.
