Cold galvanized cable tray is to use electrolytic equipment to degrease and pickle the cable tray, and then put it into a solution with zinc salt composition, and connect the negative pole of the electrolytic equipment. A zinc plate is placed on the opposite side of the cable tray, and the positive pole of the electrolytic equipment is connected to the power supply. A layer of zinc will be deposited on the cable tray by using the directional movement of the current from the positive pole to the negative pole. Cold galvanized cable tray is processed first and then galvanized, which has the effect of anti-corrosion.

同重防腐涂料一樣，冷鍍鋅電纜橋架的生產和涂裝工程也涉及到環境保護以及施工人員及公眾的職業衛生和，因此環境保護也是冷鍍鋅電纜橋架主要的發展方向。冷鍍鋅電纜橋架具有優異的性能，主要體現在以下4個方面：

Like heavy anti-corrosion coating, the production and coating of cold galvanized cable tray also involves environmental protection and occupational health and safety of construction personnel and the public, so environmental protection is also the main development direction of cold galvanized cable tray. Cold galvanized cable tray has excellent environmental protection performance, which is mainly reflected in the following four aspects:

(1)成分內不含Ph、cr、Hg等重金屬；

(1) The ingredients do not contain Ph, cr, Hg and other heavy metals;

(2)歸屬于厚膜型材料，觸變性能好，經充分?jǐn)嚢韬螅偌踊虿患酉♂寗?，即可涂裝施工。由于冷鍍鋅固體分含量高達77%，一次無氣噴涂可獲得較高的膜厚，減少了有機溶劑的揮發量，降低干燥能耗，這些均有利于環境保護。

(2) It belongs to thick film material with good thixotropy. After full mixing, with little or no thinner, it can be coated. As the solid content of cold galvanizing is as high as 77%, one airless spraying can obtain a higher film thickness, reduce the volatilization of organic solvents, and reduce drying energy consumption, which are conducive to environmental protection.

(3)經過測試證明：絕大多數冷鍍鋅的溶劑和稀釋劑內不含甲苯、酮類、鹵代烴等毒性大的有機溶劑。

(3) The test shows that most of the solvents and diluents for cold galvanizing do not contain toxic organic solvents such as toluene, ketones and halohydrocarbons.

(4)與熱浸鍍鋅相比，電鍍鋅工藝更簡單，成本更低。冷鍍鋅電纜橋架是替代熱浸鍍鋅、電弧(熱)噴鋅的很好材料，對減少三廢、降低能耗，提高環境保護的社會效益的作用明顯。

(4) Compared with hot-dip galvanizing, the electro galvanizing process is simpler and cheaper. Cold galvanized cable tray is a good material to replace hot dip galvanizing and arc (hot) zinc spraying. It plays an obvious role in reducing three wastes, reducing energy consumption and improving social benefits of environmental protection.

在各種保護鋼基體的涂鍍方法中，熱鍍鋅是優良的一種。它是在鋅呈液體的狀態下，經過了相當復雜的物理、化學作用之后，在鋼鐵上不僅鍍上較厚的純鋅層，而且還生成一種鋅—鐵合金層。這種鍍法，不僅具備了電鍍鋅的耐腐蝕特點，而且由于具有鋅鐵合金層。還具有電鍍鋅所無法相比擬的強防腐蝕性。因此這種鍍法適用于各種強酸、堿霧氣等強腐蝕環境中。

Hot dip galvanizing is an excellent coating method for protecting steel substrate. It is in the liquid state of zinc, after quite complex physical and chemical actions, not only a thick pure zinc layer is plated on steel, but also a zinc iron alloy layer is formed. This plating method not only has the corrosion resistance characteristics of galvanization, but also has a zinc iron alloy layer. It also has strong corrosion resistance that can not be compared with that of electrogalvanizing. Therefore, this plating method is applicable to various strong acid, alkali fog and other corrosive environments.

以上就是為大家介紹的有關山東電纜橋架的詳細的介紹,希望對您有所幫助.如果您有什么疑問的話,歡迎聯系我們.我們將以的態度,為您提供服務http://www.hongxingbm.com

The above is a detailed introduction to Shandong cable tray, and I hope it will be helpful to you. If you have any questions, please contact us. We will provide you with professional services http://www.hongxingbm.com
